Melt King DNX General garbage reducer and dryer

メルトキングDNX 生ごみ、残飯、野菜ごみ乾燥減量処理装置

イ High recycling rate garbage volume reducing dryer

Most of the calorie value remains, so high calorie solid fuel can be recycled.

Depending on the processed material, it can be recycled into feed and fertilizer.

   メルトキング 攪拌乾燥炉
メルトキング MD 脱臭室、減菌室
メルトキング 排出作業
メルトキング 処理物



Possible to reduce volume max 98%

Garbage, food waste are cut off oxygen in the reduction room and indirectly heated and dried to achieve significant weight loss. The weight loss rate depends on the type of treated material and the water content , and a maximum weight loss of 98 % is possible. For example, food waste will be reduced to 98%.

No dioxin, dust  scattering and smell

Because it is indirect heating, there is no scattering of dust, and it is an eco-friendly system that does not generate dioxin because it does not incinerate. Patented deodorizing technology significantly reduces odor during heating and reducing driving noise.

Significant  processing cost reduction
Originally, it costs a lot to manage and dispose of it as industrial waste, but by introducing it, it is possible to greatly reduce the treatment cost.

Prevention of confidential documents leakage

It can also be used to process important documents.By processing in the facility, it is possible to prevent leakage of confidential information and personal information.

Safety that can be used in residential areas

Both the weight loss room and the deodorization room have a double structure, ensuring high safety. The processing temperature in the weight reduction chamber is as low as about 180℃ambient temperature, and there is no oxidation reaction, so the equipment lasts longer. With a vibration sensor, it responds to emergencies.

Effective use of recycled waste

Since there is no combustion(oxidation reaction) of the processed material in the weight loss room, the processed material is not ash but a combustible solid. Most of the calorie solid fuel can be recycled. Depending on the content of the processed material, it can be recycled into feed and fertilizer.

Easy Operation

Easy operation has been achieved in pursuit of operability and safety. Safety operation makes it easy to load and discharge processed materials.

Possible of fast and hygienic treatment

The introduction inside the facility enables quick processing  of the waste and improves the sanitary environment of the facility.

Melt King PDF brochure
Contact us



Objetcs those Melt King DNX can process

メルトキング 白菜メルトキング 残飯メルトキング レタスメルトキング もやし
  Chinese cabbage        Leftovers            Lettus             Sprout
メルトキング レタス たまねぎメルトキング とまとときゅうりメルトキング パンメルトキング こんにゃく
    Onion           Tomato and cucumber       Bread          Konjac
メルトキング ポテトメルトキング ももメルトキング 大根メルトキング 納豆
    Potato and banana         Peach            Radish           Soy bean
めるとメルトキング 家畜の糞メルトキング 汚泥メルトキング 珪藻土
           Food waste          Livestock dung         Sludg        Diatomaceous earth



Customers of Melt King DNX

メルトキング 弁当工場メルトキング 弁当工場メルトキング 社員食堂メルトキング もやし工場
    Box lunch factory             Box lunch factory               Employee cafeteria              Bean sprout factory
DNX-500                         DNX-1000                         DNX-1000                    DNX-1000
Cooking waste,vegetables     Cooking waste, vegetables   Cooking waste, leftovers    Sprout
メルトキング 食品加工工場メルトキング 菓子工場メルトキング 香辛料工場メルトキング 漬物工場
Process food factory     Onfectionery factory      Spice factory      Pickle factory
DNX-1000                      DNX-1000                       DNX-1000                           DNX-1000
Fruites, Tofu rice       Potato       Wasabi, spice         Chinese cabbage
メルトキング 産廃業者メルトキング リゾートホテルメルトキング ゴルフ場メルトキング 南極昭和基地
Industrial waste collection company   Resort hotel     Golf Course    Japan Antarctic Station
DNX-1000                      DNX-500                            DNX-500                           DNX-1000
Industrial waste    Fruits, vegetables, leftovers        Grass     Cooking waste,Leftovers



Melt King DNX model lineups

Model DNX-500 DNX-1000
Can
process

Food waste, cooking waste, vegetables, fruits, plants, livestock dung and combustibles materials etc

Can not
process

Vinyl chloride products, petroleum, oil, metal, iron, steel, glass, stone, porcelain, bound paper or books, large amount of cloths / plastic, infectious waste etc

Size WxDxH

1,910 × 1,350 × 2,425 mm

2,340 x 1,510 x 2,535 mm

Exhaust tower

400mm

Weight

1,900kgs 3,000Kgs

Process
capacity

500 litters/ badge 1,000 litters / badge

Inlet size

650 X 400 mm

Electric power

3 phase 200 voltage

Power
consumption

1.3kw/h 2.3kw/h
Fuel1

Kerosene JIS No.1

Fuel
consumption
6~8 litters/ h 8~13 litters / h
Fuel 2
In case of gas
City gas 13A 2kpa

Can be changed to LPG

Gas
consumption
4~6㎥ / h 5~9.6㎥ / h
Processing
time
6~10 h / badge 8~13 h / badge
Accessory

Kerosene use : Kerosene tank ( 198 liters), cleaning stick, saucer, grease

Gas use : cleaning stick, saucer, grease
